1100D 33 PVC blue PES laid scrim Suppliers, Company - Zhejiang Shengdannu New Materials Technology Co.,Ltd.

1100D 33 PVC blue PES laid scrim

PES Laid Scrim

Item	Test Standards	Data	Unit
Size of Scrim	/	3*3	/cm
GSM	EN 29073-1	131	g/m²
Thickness	EN 29073-2	0.38	mm
Breaking Strength	EN 29073-3	1100	N/5cm
Tensile Strain	EN 29073-3	39	%
Strength @ 5% Elongation	EN 29073-3	119	N/5cm
Strength @ 15% Elongation	EN 29073-3	202	N/5cm
Resistant to Tear	DIN 53363		N

How long does it take to get a reply after we send you an inquiry?

We will reply to the price request within two working days.

Are you a direct manufacturer or a trading company?

Our factory was built in 2002 and now we have 20000 square meters working area.

What products can you offer?

We mainly produce Laid Scrim and films that laminated laid scrim products.

What application areas do your products mainly involve?

Our product can be used in any board and film application area to improve the strength and stabilize the dimension change under stressful conditions. Especially in the automotive area， wind-power blades， PVC tarpaulin， swimming pool PVC flooring, indoor PVC flooring， road construction and repairing, waterproof flooring, cement board and etc.

Can you make customized products?

Yes, we mainly make customized products, we develop and produce products according to the data or samples provided by customers.

What is the production capacity of your company?

We have a fully automatic scrim and lamination production line, with a monthly output of 1.8 million square meters.

Product Knowledge

1100D 3*3cm PVC blue PES laid scrim is a type of composite material that is commonly used in the construction and industrial textiles industries.The "3*3cm" refers to the size of the pattern in which the fibers are laid, with each square measuring 3 centimeters on each side. The material is composed of two layers - a polyvinyl chloride (PVC) layer and a polyethylene terephthalate (PES) layer, with a laid scrim in between.

The PVC layer provides the material with excellent durability, resistance to weathering and chemicals, and a waterproof barrier. The blue color is often used for identification purposes or to indicate that the material is suitable for outdoor use. The PES layer provides the material with excellent mechanical strength and dimensional stability, ensuring that it maintains its shape and structure over time.

The laid scrim in between the layers provides the material with additional strength and stability. It is a reinforcing material that is made from a network of fibers that are woven together in a specific pattern. The laid scrim helps to distribute the load across the material and prevents it from tearing or puncturing.

PVC is a synthetic polymer that is often used for its durability, waterproofing, and resistance to weathering. PES, as mentioned before, is a type of polyester that is commonly used in the production of fibers and textiles.

Laid scrim refers to the manufacturing process used to create the material, which involves laying the fibers in a specific pattern and bonding them together with an adhesive. This creates a strong and durable material that can be used for various applications, such as in the construction industry.

Overall, 1100D 3*3cm PVC blue PES laid scrim is a specific type of reinforcement material that is characterized by its high density, specific pattern, and combination of PVC, PES, and fibers. It is often used in applications that require increased strength and durability, such as for reinforcement of concrete or plaster walls in construction.
