1100D 22 SBR PES laid scrim

PES Laid Scrim

Item Test Standards Data Unit
Size of Scrim / 2*2 /cm
GSM EN 29073-1 62 g/m²
Thickness EN 29073-2 0.34 mm
Breaking Strength EN 29073-3 748 N/5cm
Tensile Strain EN 29073-3 24.6 %
Strength @ 5% Elongation EN 29073-3 78 N/5cm
Strength @ 15% Elongation EN 29073-3 163 N/5cm
Resistant to Tear DIN 53363 N
Contact Us
  • Specifications
  • faq
  • Do You Have Any Question?
  • Haven't Found The Types You Want?

    Customized with drawings and samples

    Learn About Customization

Shengdannu New Materials

Professional and reliable manufacturer of new textiles

Established in 2002, Zhejiang Shengdannu New Materials Technology Co.,Ltd. is a professional manufacturer specializing in technical textile field. With 20 years export experience and researches on the new material field for all textile field. We started research on textile for industry on 2018. Based on a group of 10 technical people with 2 years research, we are now aimed on reinforcing textile materials for films and boards. Company imported Laid Scrim machine from German which can produce more than 60000 square-meter scrim every day with single or double layer lamination optionally.
As 1100D 22 SBR PES laid scrim Suppliers and custom Company, our main products include glass fiber and high strength polyester fiber laid scrim with 1*1 -3*3 /cm mesh. Single and double sides lamination with PVC tarpaulin, aluminium foil, PET foil, polyester non-woven fabric and glass fiber non-woven fabric. Those product widely used for indoor and outdoor waterproof system, thermal isolation system, road construction, agricultural shed, PVC flooring, cement board reinforcement and etc.,

Honor

ISO
GRS-  Global Recycle System
GRS-  Global Recycle System
GRS-  Global Recycle System

Product Knowledge

1100D 2*2cm SBR PES laid scrim is a type of composite material that is commonly used in the construction industry. The material is composed of two layers - a styrene-butadiene rubber (SBR) layer and a polyethylene terephthalate (PES) layer, with a laid scrim in between.

The SBR layer provides the material with excellent flexibility, elasticity, and resistance to abrasion, making it suitable for use in a variety of construction applications. The PES layer provides the material with excellent mechanical strength and dimensional stability, ensuring that it maintains its shape and structure over time.

The laid scrim in between the layers provides the material with additional strength and stability. It is a reinforcing material that is made from a network of fibers that are woven together in a specific pattern. The laid scrim helps to distribute the load across the material and prevents it from tearing or puncturing.

1100D 2*2cm SBR PES laid scrim is commonly used in the construction industry as a reinforcing material for roofing membranes, waterproofing systems, and other building materials. It is also used in the production of tarps, covers, and other industrial textiles.

In conclusion, 1100D 2*2cm SBR PES laid scrim is a durable and flexible composite material that provides excellent mechanical strength and dimensional stability. Its unique combination of properties makes it an ideal choice for a wide range of applications in the construction and industrial textiles industries.
